250kw / 300 Kva Doosan Generator Set Water Cooling Method Four Stroke

Ask Lasest Price
Brand Name :	FM
Model Number :	FM120GF
Certification :	ISO9001
Price :	Negotiable
Payment Terms :	T/T
Supply Ability :	100

Add to Cart

Product Details
Company Profile

250kw / 300 Kva Doosan Generator Set Water Cooling Method Four Stroke

Silent 250kw/300kVA Computer Liquid Crystal Control Korean Doosan Diesel Generator Set

Basic Info.

Conditions of Use

Land Use

Usage

Common Units, Standby Unit, Emergency Crew

Landuse Type of Unit

Ordinary

Excitation Mode

AC Rotating Exciter

Transport Package

Plywood Package

Origin

China

HS Code

8502120000

Production Capacity

1000

Product Description

Product Description

Main technical parameter for generator set

brand	Feng Mao power
manufacturer	made in china
The unit type	FM120GF
power of the assembling unit	120KW/150kva
power factor	0.8
starting mode	electrical starting
output voltage	400/230V
current output	217A
mode of connection	three-phase four-wire
rated frequency	50HZ

Introduction to diesel engine

Doosan provides engines for 10 common and very useful diesel generators, all of which meet U.S. EPA exhaust standards and have power ranges from 35kw-649kw engines. In the atmospheric temperature of 40 ºC, altitude 1000 m can maintain the output power. Cooling systems are used in the tropics to ensure output power of 0-2%. Low emission, low noise. With the latest technology jet and air compression system to bring low internal consumption and ensure excellent combustion performance and low fuel consumption. All engines meet the U.S. EPA and CARB TIER exhaust standards. Durability and low noise, simple, quick and economical installation design ideas to provide a smooth, vibration free and low noise balanced design. The piston cooling system makes it easy to control the operating temperature of the cylinder and combustion chamber.
3.Generator parameter
The nonlinear load voltage waveform is less distorted
Strong short circuit endurance
The stator winding is impregnated by vacuum pressure and covered with dampproof epoxy insulating paintThe rotor and exciter are treated with high temperature resistant insulating resin paint, which is more suitable for use in bad environment
H grade insulationThe rotor silicon steel plate is mechanically tightened
250kw / 300 Kva Doosan Generator Set Water Cooling Method Four Stroke

250kw / 300 Kva Doosan Generator Set Water Cooling Method Four Stroke

model	power KW KVA		electricity A	Diesel engine model	number of cylinders	Cylinder diameter mm	lubricating oil capacity L	oil wear g/kw.g	The unit size L×W×H	The unit weight kg
FM50GF	50	62.5	90	DB58	6	102*118	15	215	20007301150	900
FM64GF	64	80	115.2	D1146	6	111*139	18	222	22008001500	1100
FM75GF	75	93.75	135	D1146	6	111*139	18	222	22008001500	1100
FM100GF	100	125	180	D1146T	6	111*139	18	200	23008001500	1500
FM120GF	120	150	216	DP086TA	6	111*139	18	201	23008001500	1600
FM132GF	132	165	237.6	DP086TA	6	111*139	18	201	23008001500	1600
FM150GF	150	187.5	270	P086TI-1	6	111*139	18	207	255010001500	1750
FM180GF	180	225	324	P086TI	6	111*139	18	202	260010001500	1800
FM200GF	200	250	360	DP086LA	6	111*139	20	203	270010001500	1800
FM220GF	220	275	396	P126TI	6	123*155	20	205	290010501650	2400
FM240GF	240	300	432	P126TI	6	123*155	20	205	290010501650	2400
FM260GF	260	325	468	P126TI	6	123*155	25	202	300010501650	2600
FM300GF	300	375	540	P158LE-1	8	128*142	33	232	310014001850	2700
FM320GF	320	400	576	P158LE-1	8	128*142	33	232	310014001850	2700
FM350GF	350	437.5	630	P158LE	8	128*142	33	209	310014001850	2800
FM400GF	400	500	720	DP158LCF	8	128*142	35	210	312014001850	3000
FM440GF	440	550	792	DP158LDF	8	128*142	40	205	330014001850	3300
FM500GF	500	625	900	DP180LAF	10	128*142	45	200	340014001850	3500
FM550GF	550	687.5	990	DP180LBF	10	128*142	45	207	340014001850	3700
FM600GF	600	750	1080	DP222LBF	12	128*142	45	210	350014001850	4000
FM650GF	650	812.5	1170	DP222LCF	12	128*142	50	207	360014001850	4500

The above technical parameters have a speed of 1500RPM, a frequency of 50HZ, a rated voltage of 400/230v, a power factor of 0.8, and a three-phase four-wire connection.
According to customers' demand, the generator can choose famous brands such as Shanghai Stanford, Shanghai marathon, wuxi Stanford, etc.

3.60HZ generator sets can be customized according to the special needs of customers.
250kw / 300 Kva Doosan Generator Set Water Cooling Method Four Stroke

Standard equipment:

diesel engine

alternator

water cooled radiator

industrial silencer and flexible exhaust hose

maintenance-free lead-acid starting batteries and battery connect wires

output circuit breaker

digital control panel

steel base frame
